15KV-1000PF/High Voltage Doorknob Capacitors

  • 15KV-1000PF/High Voltage Doorknob Capacitors
  • 15KV-1000PF/High Voltage Doorknob Capacitors
Place of Origin XIAN, CHINA
Brand Name XIWUER
Certification ISO9001,ISO14001,ISO45001,CCC
Model Number CT8-1-15KV-1000PF
Minimum Order Quantity 5
Price Negotiable
Packaging Details Carton
Delivery Time 10-15 days
Payment Terms L/C,T/T
Supply Ability 8,000,000 pcs a year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Capacitance 5PF-2000PF Operating Temperature -30C ~ 85C
Type Low Frequency Ceramic Capacitor Insulation Resistance 100,000 MΩ Min
Rated Voltage 24KV Application Power, Hight Voltage
You can tick the products you need and communicate with us in the message board.
Leave a Message
Product Description

15KV-1000PF/High Voltage Doorknob Capacitors

High voltage ceramic capacitors are made of ceramic dielectric. The main features of high voltage ceramic capacitors is excellent withstand voltage, Excellent behavior on pulse and fast discharge conditions, Low dissipation factor, Very low partial discharge, Coated and uncoated devices available Used for various AC and DC high voltage circuit applications.

Main Technical Data


Type (pF) Capacitance DC Vol.(KV)

Charge ＆Discharge

Vol.(KV)

 Dimension(mm)

Operating

Temp.

Range
Operating Vol.

Testing

Voltage

 D H L M d
CT8-1 2500 15 22.5 10 40 13 22 5 12

－25℃

～

＋85℃
1000 20 30 15 32 13 22 / /
4000 50 15 24 / /
10000 80 23 32 / /
50 30 45 20 20 12 24 4 8
1000 45 23 32 / /
31 17 21 / /
2000 50 23 32 4 12
2700 60 20 29 / /
3800 74 23 32 / /
140 40 60 30 20 32 41 4 8
200 20 33 42 / /
820 38 27 31 / /
1000 40 27 36 4 12
3300 65 27 36 / /
5600 80 23 28 5 12
570 45 67.5 30 36 24 32 4 12
1000 50 32 36 4 12
600 50 75 35 45 34 43 4 12

－25℃

～

＋85℃
1000 50 27 36 / /
2000 60 32 41 5 12
3000 74 29 38 5 12





CERTIFICATE

15KV-1000PF/High Voltage Doorknob Capacitors 015KV-1000PF/High Voltage Doorknob Capacitors 115KV-1000PF/High Voltage Doorknob Capacitors 2
