Low Frequency Ceramic Capacitor High Voltage Doorknob Capacitors with 15KV-1000PF

Brand Name:	XIWUER
Model Number:	CT8-1-15KV-1000PF
MOQ:	5
Price:	Negotiable
Payment Terms:	L/C,T/T
Supply Ability:	8,000,000 pcs a year

Detail Information

Product Description

Detail Information

Place of Origin:

XIAN, CHINA

Certification:

ISO9001,ISO14001,ISO45001,CCC

Capacitance:

5PF-2000PF

Operating Temperature:

-30C ~ 85C

Type:

Low Frequency Ceramic Capacitor

Insulation Resistance:

100,000 MΩ Min

Rated Voltage:

24KV

Application:

Power, Hight Voltage

Packaging Details:

Carton

Supply Ability:

8,000,000 pcs a year

Highlight:

Low Frequency High Voltage Doorknob Capacitors

15KV High Voltage Doorknob Capacitors

High Voltage 1000pf doorknob capacitor

Product Description

15KV-1000PF/High Voltage Doorknob Capacitors

High voltage ceramic capacitors are made of ceramic dielectric. The main features of high voltage ceramic capacitors is excellent withstand voltage, Excellent behavior on pulse and fast discharge conditions, Low dissipation factor, Very low partial discharge, Coated and uncoated devices available Used for various AC and DC high voltage circuit applications.

Main Technical Data

Type	(pF) Capacitance	DC Vol.(KV)		Charge ＆Discharge Vol.(KV)	Dimension(mm)					Operating Temp. Range
Type	(pF) Capacitance	Operating Vol.	Testing Voltage	Charge ＆Discharge Vol.(KV)	D	H	L	M	d	Operating Temp. Range
CT8-1	2500	15	22.5	10	40	13	22	5	12	－25℃ ～＋85℃
	1000	20	30	15	32	13	22	/	/
	4000				50	15	24	/	/
	10000				80	23	32	/	/
	50	30	45	20	20	12	24	4	8
	1000				45	23	32	/	/
	1000				31	17	21	/	/
	2000				50	23	32	4	12
	2700				60	20	29	/	/
	3800				74	23	32	/	/
	140	40	60	30	20	32	41	4	8
	200				20	33	42	/	/
	820				38	27	31	/	/
	1000				40	27	36	4	12
	3300				65	27	36	/	/
	5600				80	23	28	5	12
	570	45	67.5	30	36	24	32	4	12
	1000	45	67.5	30	50	32	36	4	12
	600	50	75	35	45	34	43	4	12	－25℃ ～＋85℃
	1000				50	27	36	/	/
	2000				60	32	41	5	12
	3000				74	29	38	5	12
