Integrated Instrument Transformer 24kVAC 50pF High Voltage Ceramic Capacitor With Withstanding Voltage Test At 50Hz

Withstanding Voltage test one by one 24kVAC 50pF High Voltage Ceramic Capacitor for Voltage Multiplier Circuit Module

Product Description:

Each of our High Voltage Ceramic Capacitors is rigorously tested under a testing voltage of 1V±0.2V to ensure it meets our high performance standards. Additionally, we guarantee that the partial discharge levels will not exceed 10pC for the following nominal voltages: 3.96kVAC, 7.92kVAC, 13.2kVAC, 26.4kVAC, and 44.5kVAC.
Our High Voltage Ceramic Capacitor is classified as a high voltage ceramic capacitor, and is perfect for presence indication devices. It is designed to withstand high voltages, withstanding voltage (insulating oil) at 32kVAC5min, 41kVAC5min, 52kVAC5min, 70kVAC5min, and 115kVAC5min, depending on the nominal voltage rating.
Choose our High Voltage Ceramic Capacitor for a high reliability ceramic capacitor that is perfect for use in presence indication devices ranging from 3.6kV to 40.5kV. With unparalleled performance and high voltage capabilities, it is the perfect solution for all your high voltage needs.

Features:

• Product Name: High Voltage Ceramic Capacitor
• Major Customers: ABB, Schneider, GE, ZTE, XD Electric, XJ Electric, PingGao Electric and etc.
• Company Overview: Xian Xiwuer Electronic and Info. Co., Ltd is a wholly state-owned company with a registered capital of CNY 101.465 million (exchanged to USD15.85 million), owning total assets of CNY315 million (traded to USD 49.22 million).
• Nominal Voltage: 3.6kVAC, 7.2kVAC, 12kVAC, 24kVAC, 40.5kVAC
• Lightning Impact: 125kV
• Features:
  • Long product life
  • Made of SrTiO3 ceramic material
  • Low dielectric loss
  • High withstand voltage
  • Capacitance accuracy 10%
  • Low bias characteristics

Live line capacitor for live display device, ceramic rod for capacitive insulator, high temperature ceramic capacitor

Technical Parameters:

Applications:

The capacitance of this high voltage ceramic capacitor is 1V, 1KHz,25℃ 200pF. It falls under the product category of high voltage ceramic capacitors and is part of XIWUER's main products. Their main products include smart embedded epoxy poles, integrated instrument transformers, capacitive voltage dividers, high voltage capacitor rods, high voltage film capacitors, high voltage resistors, primary and secondary integrated intelligent assembly and components with the function of voltage measurement, current measurement, protection, temperature monitoring, and power supply, medium-high voltage components/parts/assembly, surge protective devices for power supply systems, chips for lightning devices, zinc oxide varistors, and thermistors.
The high voltage ceramic capacitor by XIWUER is used in various applications such as low-power high-voltage multiplier circuit modules, medical equipment power supply, electrostatic spray equipment, electrostatic generating circuit, X-ray equipment, high-voltage negative ion generator, high-voltage DC generator, and voltage multiplier circuit module. This capacitor can withstand a voltage of 32kVAC5min, 41kVAC5min, 52kVAC5min, 70kVAC5min, and 115kVAC5min when insulated with oil.

Support and Services:

Our High Voltage Ceramic Capacitor product comes with a range of technical support and services to ensure its optimal performance:

• We provide detailed datasheets and specifications for our products to assist in selection and integration.
• Our technical support team is available to answer any questions or concerns about the product's performance or application.
• We offer customization services to meet specific customer requirements, including capacitance value, voltage rating, and size.
• Our quality control measures ensure consistent and reliable performance, and we offer product testing and validation services upon request.
• In the unlikely event of a product failure, we offer warranty and repair services to ensure customer satisfaction and minimal downtime.

Packing and Shipping:

Product Packaging:

• The high voltage ceramic capacitor will be packaged in a protective plastic tray.
• The tray will be sealed with a clear plastic cover to prevent any damage during shipping.
• The packaged product will be placed in a cardboard box.
• The box will be labeled with the product name, quantity, and any necessary handling instructions.

Shipping:

• The packaged product will be shipped via a reliable carrier service.
• The carrier service will be chosen based on the destination and delivery time requirements.
• The package will be tracked and the customer will receive updates on the shipping status.
• The package will be insured to cover any damages or loss during shipping.

FAQ:

Q: What is the brand name of this high voltage ceramic capacitor?
A: The brand name of this high voltage ceramic capacitor is XIWUER.
Q: What is the model number of this high voltage ceramic capacitor?
A: The model number of this high voltage ceramic capacitor is 15kV 150pF.
Q: What certifications does this high voltage ceramic capacitor have?
A: This high voltage ceramic capacitor is certified by ISO9001, ISO14001, and ISO45001.
Q: What is the minimum order quantity for this high voltage ceramic capacitor?
A: The minimum order quantity for this high voltage ceramic capacitor is 1 piece.
Q: What is the delivery time for this high voltage ceramic capacitor?
A: The delivery time for this high voltage ceramic capacitor is 5-7 days.
