Product Description

The 35kV 45pF High Voltage Ceramic Capacitor is a high-voltage ceramic capacitor used in electronic circuits requiring high voltage withstand capability, stable capacitance, and reliable insulation performance.

The capacitor is manufactured with ceramic dielectric materials and a stable internal structure to maintain consistent electrical characteristics under high voltage operating conditions. It features low dielectric loss, high insulation resistance, and good voltage withstand capability, making it suitable for high-voltage and high-frequency circuit applications.

With a rated voltage of 35kV DC (35000V) and a capacitance value of 45pF, this capacitor is suitable for applications where high voltage capability, compact structure, and stable electrical performance are required.

It is commonly used in high voltage power supplies, pulse circuits, protection circuits, industrial electronic equipment, communication systems, and high voltage testing equipment.

Key Features

High Voltage Withstand Capability

Rated voltage up to 35kV DC (35000V), suitable for high-voltage circuits requiring strong insulation performance and reliable voltage endurance.

Stable Capacitance Performance

The 45pF capacitance value provides consistent electrical characteristics and helps maintain stable circuit operation.

Low Dielectric Loss

The ceramic dielectric material provides low dielectric loss characteristics, supporting stable operation in high-frequency and high-voltage circuits.

High Insulation Resistance

High insulation resistance improves electrical stability and supports long-term operation in high-voltage environments.

Compact Structure

Compact design allows flexible installation in high-voltage electronic equipment and systems with limited space requirements.

Technical Parameters

Applications

The 35kV 45pF High Voltage Ceramic Capacitor is commonly used in:

• High voltage power supplies
• Pulse circuits
• High frequency circuits
• Voltage protection circuits
• Industrial electronic equipment
• High voltage testing equipment
• Communication systems
• Medical electronic devices

Product Advantages

• Stable electrical characteristics under high voltage conditions
• High insulation resistance
• Low dielectric loss
• Good high-frequency performance
• Strong voltage withstand capability
• Compact structure
• Long service life
• Custom specifications available
